SKF: Constant Fill Fluid Couplings

HYDRAULIC COUPLING – TURBO COUPLING

The SKF series of Constant Fill Fluid Couplings is used on all industrial equipment types driven by internal combustion engines up to 180 kW requiring a tight flywheel mounting. By transmitting power through a fluid, they improve overall performance and protect both driving and driven machines.

BENEFITS OF CONSTANT FILL FLUID COUPLINGS

When you drive through Transfluid Hydraulic Coupling you profit from these Basic Benefits.

1. Frees engine during heavy starts
   During heavy starts and sudden running load increases, engine lugging is prevented. The Fluid Coupling simply “slip” while it smoothly picks up the load.
2. Provides smoothly drive
   The mechanical connection is eliminated; power and torque are transmitted entirely through fluid mass and velocity. The result is a smooth, sustained flow of energy minus the shocks and strains which, with mechanical drives, cut equipment life.
3. Prevents transmission of shock loads
   Fluid Couplings protect both driving and driven equipment by smoothing out shock loads and preventing them from striking solid resistance.
4. Assures damping effects
   Torsional vibrations from the engine are drastically dampened by the Fluid Coupling, increasing the life of the entire driveline.
5. Transmits full input torque
   The patented Transfluid Circuit design delivers output torque always equal to input torque. The engine can turn at its max torque-rpm, even when driven is at stall.
6. Radial load capability.
   The SKF series includes the SKFE line which allows the installation of a pulley on output shaft.
