HYDRAULIC COUPLING – TURBO COUPLING
The KX is a constant fill fluid coupling with a special patented circuit designed to start up large inertia machines driven by electric motors. The circuit includes two internal tanks connected by a scoop. The scoop works like a differential pump transferring the fluid from one chamber to the other and finally into the coupling working circuit through external adjustable valves. This double chamber allows a long starting time with very low starting torque and absorbed current by the electric motor, virtually isolating the inertia of the driven machine.
The coupling can work using both oil and treated water as standard.
HYDRAULIC COUPLING: OPERATING CONDITIONS
The fluid quantity in the working circuit is less than in traditional constant fill fluid couplings, as the fluid level is much lower than the rotating axis. The reduced fluid quantity in the working circuit allows low starting torque. During input rotation the scoop transfers the fluid from tank A to tank B and then, through an adjustable valve for starting time regulation, to the working circuit.
MAIN FEATURES OF THE KX SERIES CONSTANT FILL FLUID COUPLINGS
Starting stall torque below 50% of the electric motor nominal torque.
Starting torque limitation also below nominal torque.
KX allows the fluid coupling removal without moving the electric motor or the driven machine avoiding the realignment.
KX has a fusible plug that in case of intervention, releases the fluid from the working circuit to a tank preventing leakages into the ambient.
A steel body design suitable for underground mines is available.
The fluid filling operation is quite easy and apart from some particular cases, it is not required to change the fluid during the test starting: the starting time can be optimized by changing on the externally adjustable valves.
KX fluid coupling is very suitable for driving machines having large powers and inertia: typical applications are mills and belt conveyors
Our turbo coupling series is also available certified according to directive 94/9/EC (Atex) covering all categories.
